Description
Phase range of Linear Compact Switchboxes to suit diaphragm valves and actuators
- Suitable for:
- Phase LC Actuator, Saunders EC, SSC and S360 actuators for diaphragm type valves (spring close, spring open and double acting models)
- Size Range:
- DN8-50 inclusive
- Enclosure Connection:
- 1 x M20 x 1.5 (standard),
- 1/2” NPTF (optional),
- Optional 2 x entries for solenoid back wiring
- Enclosure Rating:
- IP67
- Terminals:
- 5 Way 2.5mm² conductor plus 2 terminals for back wiring where specified
- Switch Options:
- No. of switches – 1 or 2. / S.P.D.T. / Silver (standard) / Gold (optional). No. of sensors 1 or 2 , 2 wire NAMUR , 2 wire PNP/NPN, 3 wire PNP, 3 wire NPN.
- Method of Calibration:
- Self Calibrating
- Material of Construction:
- Acetal, Black
- Seals:
- Viton Rubber
- Temperature Range:
- Safe Area, -10 Deg C to +80 Deg C (non IS)
- EExia IIC, T5 -10 Deg C to 80 Deg C, T6 -10 Deg C to 65 Deg C
- Standards:
- EU directive compliance.
- CE marked.
- Machinery directive 89/392/EEC.
- LV directive (micro switch variants).
- 73/23/EEC amended 93/68/EEC.
- EMC directive (sensor variants) 89/336/EEC. amended 92/31 EEC & 93/68/EEC.
- ATEX directive
